SILENT-PLUG AND LUG PLUG PHONE PLUGS
PHONE: 773 792-2700
148
JACKS AND PLUGS
?
* Please visit the product pages on our website for the most up-to-date product information
SILENT-PLUG PHONE PLUGS
2-CONDUCTOR PLUGS
No. 172
Part
Number
Terminals
Typical
Mating Jack
Handle
Handle Part
Number
Silent-Plug plugs have unique circuit-closing device—
Screw
stops hums, squeals and pops when plug is removed
from jack. One-piece tip rod assembly insures plug
quality. Utilizes cables up to .25" diameter (parallel or
shielded cable). U.S. Patent No. 2,664,475.
172
(Replacement
Screw Part No.
P-1011-3)
2 required
11
Shielded
Two-Piece 1 Ins.
Tube A-1006-3
SPECIFICATIONS
Two-piece 1 Ins.
Tube A-1137-1
Sleeve, Tip and Body: Nickel-plated copper alloy.
Terminals: Copper alloy, tin-plated.
181
182
Solder Lug and
Cable Clamp
Shielded 2
T-1014-1 Handle,
Screw: Cadmium plated (screws size 3-48).
Handles: Shielded machined copper alloy nickel-plated.
Tubular insulator inside handle.
A-1137-2 Ins. Tube
1. 2-piece shielded handle with built-in cable clamp for .25" diameter
cable. Handles: Number T1123-1 , handle; Number T1124-1 , cap; Number
T-1125 , rubber washer. 2. Mylar tube insulation for greater protection.
2-Conductor “Silent Plug”, No. 172
No. 181
No. 182
LUG ? -PLUG PHONE PLUGS
2-CONDUCTOR PLUGS
Part
Typical
Handle Part
Number
350
Terminals
Mating Jack 1
Handle
Black
Number
M-1002
Nos. 350, 351, 355
No. 380
2P-1216
380
Solder Lug
11
Shielded
Handle: T-1060-1
Insulator: A-1007-2
Similar to Littel-Plug phone plug. Same molded handles as
used on Littel-Plug; metal handle, bright nickel-plated, only
1" long. Fits all standard jacks. See drawing for details.
SPECIFICATIONS
Sleeve, Tip and Body: Nickel-plated copper alloy.
Terminals: Solder lug: copper alloy, tin-plated.
Screw: plated steel.
Handles: Shielded: Nickel-plated copper alloy.
Molded: black or red plastic.
1 Switchcraft part numbers. See Jacks Section for additional mating jacks.
INSULATING
TUBE ON #380
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
